We are a leading manufacturer specializing in high-density multilayer printed circuit boards and specialty boards. With certifications including UL, ISO9001:2015, ISO14001:2015, CQC, IATF16949:2016, and "National Military Standard," we provide top-quality products and services. Our extensive product range includes multilayer boards, impedance boards, high-frequency boards, high TG thick copper foil boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, specialty boards, and customized solutions. Driven by technological innovation, our products are widely used in industries such as communication equipment, industrial control, automotive electronics, energy and power, medical devices, IoT, research institutions, aerospace, and defense. With over 19 years of experience, we have served over 1,000 technology innovation-oriented enterprises with rapid prototyping and mass production services. We are committed to delivering cutting-edge solutions and exceeding customer expectations in the dynamic electronics industry.
| Rigid PCB Manufacturing Capability | ||
|---|---|---|
| Category | Volume production | Sample processing |
| Layer count | 1-68L | 64 Layer |
| Max thickness | 10mm (394mil) | 14mm (551mil) |
| Min line width/space (Inner layer) | 2.2mil/2.2mil | 2.0mil/2.0mil |
| Min line width/space (Outer layer) | 2.5mil/2.5mil | 2.2mil/2.2mil |
| Alignment (Core board) | ±25um | ±20um |
| Inner layer alignment | ±5mil | ±4mil |
| Max copper | 6Oz | 30 oz |
| Holes size (Mechanical drilling) | ≥0.15mm (6mil) | ≥0.1mm (4mil) |
| Holes size (Laser drilling) | 0.1mm (4mil) | 0.050mm (2mil) |
| Max size (Unit size) | 850mm X 570mm | 1000mm X 600mm |
| Max size (Panel size) | 1250mm X 570mm | 1320mm X 600mm |
| Aspect ratio (Unit size) | 20:1 | 28:1 |
| Aspect ratio (Panel size) | 25:1 | 35:1 |
| Material (Lead-free / Halogen-free) | EM827, 370HR, S1000-2, IT180A, EM825, IT158, S1000 / S1155, R1566W, EM285, TU862HF | |
| High-speed PCB material | Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, N4000-13 Series, MW4000, MW2000, TU933 | |
| High-frequency PCB material | Ro3003, Ro3006, Ro4350B, Ro4360G2, Ro4835, CLTE, Genclad, RF35, FastRise27 | |
| Others | Polyimide, Tk, LCP, BT, C-ply, Fradflex, Omega , ZBC2000 | |
| Surface finished | HAL, HAL-LF, ENIG, IMMERSION TIN, OSP, IMMERSION SILVER, GOLD FINGER, Hard Gold/Soft Gold Plating | |
| Special technology | Blind & buried holes, Via in pad, Semi-plating holes, Counterbore, Step mounting holes, drill Mixed RF PCB, Busbar PCB | |
We ship PCB orders with the following options:
| Layer | Sample Shortest lead time | Sample Standard lead time | Mass production lead time |
|---|---|---|---|
| 2 layer | 24 h | 3 days | 6-7 days |
| 4 layer | 36 h | 5 days | 8-10 days |
| 6 layer | 48 h | 5 days | 8-12 days |
| 8 layer | 72 h | 5 days | 9-12 days |
| 10 layer | 4 days | 7 days | 14 days |
| 12 layer | 4 days | 7 days | 16 days |
| 14 layer | 5 days | 8 days | 16 days |
| 16 layer | 5 days | 9 days | 18 days |
| 18 layer | 7 days | 10 days | 18 days |
| 20 layer and above | To be negotiated | To be negotiated | To be negotiated |
24h technical support
24h gerber files handing complete EQ with 4-8 hours
Support 400 new project engineering review
RS-274-X & RS-274-D CAD DXP Protel 99 SE PADS GC-CAM
All processes running 24 hours
Monthly more than 10K high mix part number is production
More than 100 QTA orders every day
One-step service from prototype to mass production
24 hours quick response
4 hours quick response for quotation
We are capable of volume producing PCBs with 1 to 68 layers, and up to 64 layers for standard quick-turn sample processing.
We support high-speed PCB materials such as Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, and N4000-13 series. For high-frequency, we support Rogers (Ro3003, Ro3006, Ro4350B, Ro4835), CLTE, RF35, Genclad, and FastRise27.
Our shortest quick-turn lead times are 24 hours for 2-layer samples, 36 hours for 4-layer, 48 hours for 6-layer, and 72 hours for 8-layer samples.
We accept industry-standard formats including Gerber RS-274-X and RS-274-D, CAD, DXP, Protel 99 SE, PADS, and GC-CAM files.
Our manufacturing processes strictly conform to ISO 9001:2015, ISO 14001:2015, IATF 16949:2016, UL, CQC, RoHS, and REACH quality standards. We run 100% inspection processes based on customer requirements and IPC criteria.
We provide multiple shipping methods including express air shipping (UPS, DHL, TNT, CTS, and FedEx), railway shipping, sea freight, or any shipping method designated by our customers.
